Sh 2-151

Coordinates: (108.58°, -2.75°)
Distance: 2400 pc, Size: 14.0 pc
Source: 1982ApJS...49..183B

[ Find on map | See details ] 		Sh 2-151

The only thorough paper that analyses Sh 2-151 adopts a kinematic distance of 5800 pc. Five molecular clouds are part of the Sh 2-151 complex and have a total of 29 thousand solar masses. About 700 solar masses has been ionised by an unseen star that is likely obscured by dust in one of the molecular clouds.

A fuzzy but interesting image that shows the molecular cloud structure of Sh 2-151 can be seen in this MSX mid-infrared image here. This image is very similar to the radio image shown in figure 2a of the above mentioned paper.

Sh 2-152

Coordinates: (108.80°, -1.00°)
Distance: 4705 pc, Size: 5.3 pc
Source: 2003A&A...397..213P

[ Find on map | See details ] 		Sh 2-152

The adjacent HII regions Sh 2-152 and Sh 2-153 appear to be physically related, with a major source of the ionising radiation being located in Sh 2-152 in an unnamed O9V star.

Sh 2-153

Coordinates: (108.80°, -1.00°)
Distance: 4705 pc, Size: 5.3 pc
Source: 2003A&A...397..213P

[ Find on map | See details ] 		Sh 2-153

The adjacent HII regions Sh 2-152 and Sh 2-153 appear to be physically related with Sh 2-153 being the larger and fainter nebula in the image.

Sh 2-154

Coordinates: (108.96°, 1.59°)
Distance: 1000 pc, Size: 17.5 pc
Source: 2000ApJ...537..221U

[ Find on map | See details ] 		Sh 2-154

Distance should be corrected to 1000 pc.

Sh 2-155

Coordinates: (110.15°, 2.61°)
Distance: 730 pc, Size: 12.7 pc
Source: 1982ApJS...49..183B

[ Find on map | See details ] 		Sh 2-155

The Cave Nebula interacts with the Cepheus B molecular cloud.

Sh 2-156

Coordinates: (110.10°, 0.00°)
Distance: 4891 pc, Size: 5.1 pc
Source: 2003A&A...397..213P

[ Find on map | See details ] 		Sh 2-156

Also called IC 1470, this HII region is part of the star cluster NGC 7510. It appears to be ionised by a single O7 class star. The bright core is only one of five distinct and apparently independent emission sources within a giant molecular cloud. The distance is estimated to be about 3500 to 4000 parsecs.

Sh 2-157

Coordinates: (111.29°, -0.66°)
Distance: 2500 pc, Size: 65.5 pc
Source: 1982ApJS...49..183B

[ Find on map | See details ] 		Sh 2-157

This is a ring nebula around WR 157, in the Basel 3 (Markarian 50) cluster that is in turn part of Cas OB2.

Sh 2-158

Coordinates: (111.50°, 0.80°)
Distance: 2800 pc, Size: 1.3 pc
Source: 2004ApJ...616.1042O

[ Find on map | See details ] 		Sh 2-158

This is NGC 7538, a major star formation region in Cas OB2. It is surrounded by the much larger diffuse nebula Sh 2-161B.

Sh 2-159

Coordinates: (111.60°, 0.40°)
Distance: 6334 pc, Size: 1.7 pc
Source: 2003A&A...397..213P

[ Find on map | See details ] 		Sh 2-159

Both Sh 2-158 (NGC 7538) and Sh 2-159 are embedded in the 595 thousand solar mass molecular cloud [UUT2000] Cloud G. This cloud is surrounded by the much larger diffuse nebula Sh 2-161B.

All of these objects are part of the dusty Cas OB2 association.

Russeil gives a distance estimate of 2970 +/- 310 parsecs for Sh 2-259 in a 2007 paper and identifies an O9 V class ionising star. However, she gives no catalog designation and neither SIMBAD nor the Reed catalog lists a star at the location she provides.

A wide area image that includes Sh 2-159 can be seen here.

Sh 2-160

Coordinates: (111.93°, 4.08°)
Distance: 900 pc, Size: 20.9 pc
Source: 1982ApJS...49..183B

[ Find on map | See details ] 		Sh 2-160

The HII region Sh 2-160 is located near or within the Cep OB3 association, which is part of the relatively nearby Cepheus molecular clouds, as can be seen on this face-on map. Sharpless lists three possible ionising stars including the B0 III giant HD 218323, which Humphreys assigns to Cep OB3.

You can read more about the Cep OB3 association towards the bottom of the page describing the Brain and Bubble (120° - 110°) sector, which is part of the Commentary on the Galactic Plane.

You can see a good image by Mel Martin of this nebula here.
